AWM Series Dynamic Monitor Arm

Unlock Workspace Potential

The AWM Series Dynamic Monitor Arm is the ideal solution for agile spaces/ multi-user environments for single and multiple screen options. The cleverly designed lever-action system provides easy adjustment, attachment and removal of the modular components. Quick release mounting heads enable rapid changing of displays. The modular range includes desk and wall mount, and spring-assisted height adjustability.

QTY
Features / Specifications
Finish
Powdercoat
Warranty
10 years
Lead Time
4 - 6 weeks
Misc
  • Easy to install and re-configure with quick display release and arm fixing mechanism.
  • Built-in optional arm rotation limiters to prevent interference with walls, partitions or other displays.
  • Three points of articulation and landscape to portrait rotation.
  • Adjustable tilt: 45° up and 45° down
  • Adjustable pan: 190° at the VESA head
  • Finish options include black, silver and aluminium
  • Bolt through or desk clamp mounting options
  • Notebook arm attachment
Dimensions
Post height
135mm, 400mm, 750mm
Maximum Forward Arm Reach
618mm
Height Adjustment Range
315mm
Standard VESA Mounting Bracket
75/100mm x 75/100mm
Weight Capacity
Flat Monitor 9KG / Curved Monitor 6KG
Care & Maintenance
Cleaning Instructions

For general care and maintenance, a cloth dampened with water or used with an environmentally friendly all-purpose cleaner can be used to remove most spills and marks. Surfaces will generally resist staining, however spills such as beetroot, grape or berry juice, first aid preparations, concentrated bleach oven cleaners, dishwasher detergents, hair colouring and artificial dyes, and solvent based pen ink should be wiped away promptly to prevent stains. By gently rubbing the surface with a clean, dry cloth the natural brightness of the laminate surface will be restored.

Metal surfaces should be cleaned at least once a year, more frequently in areas that are affected by salt. Remove any surface deposits with a soft wet sponge, and clean by gently rubbing the surface with a soft, non-abrasive brush and a mild detergent. Stubborn surface stains will require the use of a solvent such as isopropyl alcohol or methylated spirits, rinsing afterwards with water. After cleaning dry all metal surfaces with a soft clean cloth.
